Proud of helping steel structure solutions
8 Years
| Ask Lasest Price | |
| Brand Name : | KAFA |
| Model Number : | Steel workshop-014 |
| Certification : | ISO 9001 |
| Price : | Negotiate |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 20000 square meter/month |
| Delivery Time : | 30-45days |
Prefabricated steel structure workshop with hot rolled steel profiles
Steel structure of prefabricated workshop description:
The Features of Steel Structure Building:
This steel structure product can be installed in any weather. Also, the building has the advantage of fire-proof, heat/cold-insulation, non-shrinking and enlarge the work size and have little pollutions, we produce and install different kinds of steel structure buildings which have a good framework. They are safe, easy to install and disassemble, can be used multiple times without special tools. Specially used in warehouse, workshop, temporary office, etc. We have an excellent designing team and we can produce according to the customers' requirements.
Advantages:
1. Prefabricated: Fast and easy installation, save time and labor;
2. Customized design: different size, various layout, shape and
appearance;
3. Light weight: lighter than concrete;
4. Removable
5. Environmental Friendly: recyclable, no waste produced;
6. High strength: can resistance grade 8 earthquake, water proof,
fire proof, can resist strong wind and heavy snow.
7. Long life span: more than 50 years.
8. Wide span: single or multiple spans, maximum span 60m without
middle columns.
Technical Parameters
| Description | ||
| Main Components | Base | Concrete and steel foundation anchor bolts |
| Main frame | Hot Rolled or Welded H-Section Steel | |
| Material | Q235B, Q345B or others as per client's requests | |
| Purlin | C/Z purlin: Size from C120~C320, Z100~Z320 | |
| Bracing | X-type or other type, angle or round pipe | |
| Bolt | Plain or High-strength bolt | |
| Roof & wall | EPS / Rockwool / PU Sandwich panel or colored steel sheet | |
| Door | Electric flat door | |
| Window | Aluminum or PVC window | |
| Surface Coating | Anti-rust Paint or Hot Dip Galvanize | |
| Sheet | 0.3-0.8mm galvanized or color coated steel sheet | |
| Accessories | Translucent skylight sheet, Ventilators, etc. | |
| PVC Down pipe, Galvanized / SS304 gutter, etc. | ||
| Usages | 1. Workshop, warehouse, plant, storage | |
| 2. Steel web frame structure | ||
| 3. High rise building project | ||
| 4. Others steel structure buildings | ||
| Packing | Main steel frame without packing load in 40' OT or 40'HQ | |
| Roof and wall panel load in 40' HQ | ||
| Drawing | By client or RPIC | |
| Design Parameters | If need design from Honkae, please supply following parameters: | |
| 1) Length, width, eave height, roof apex | ||
| 2) Live Load, Wind Speed, Seismic Load, Snow Load etc. | ||
| 4) Quantity and sizes for doors and windows | ||
| 5) Other information if necessary | ||
1. Preparing Material⇒2. Cutting⇒3. Assembling⇒4. Automatic submerged arc welding⇒
5. Flange plate of straightening⇒6. Welding⇒7. Assembly dimensions inspecting⇒
8. nondestructive testing⇒9. shot blasting and descaling⇒10. Spray paint processing⇒
11. Measurement of coating thickness⇒12. Packaging⇒13. Delivery⇒Other: Secondary processing
|
|
